PoE PD Modules for OEM Devices
Corecon manufactures Power over Ethernet PD modules for embedded OEM devices, covering 13W to 90W power ranges, IEEE 802.3af/at/bt standards, and 3.3V to 48V output options.
- IEEE 802.3af / 802.3at / 802.3bt compliant
- 13W / 30W / 45W / 60W / 75W / 90W module series
- 3.3V / 5V / 12V / 24V / 48V output options
- PoE evaluation boards available
- OEM output voltage and pinout review
IEEE Standards
802.3af / at / bt
Power Range
13W–90W
Output Options
3.3V–48V DC
Validation
Evaluation Board Available
Manufacturing
OEM / ODM Support
Technical
Engineering Review
PoE PD Module Series
Select a PoE PD module series by power level, IEEE standard, and output voltage requirement. Corecon provides standard series for evaluation and OEM integration.
| Series | Power | IEEE Standard | Output Options | Recommended Use |
|---|---|---|---|---|
| CT-1300 Series | 13W | IEEE 802.3af | 3.3V / 5V / 12V | Sensors, access control, low-power IoT devices |
| CT-3000 Series | 30W | IEEE 802.3at | 5V / 12V / 24V | IP cameras, wireless APs, POS terminals |
| CT-4500 Series | 45W | IEEE 802.3bt Type 3 | 5V / 12V / 24V | Smart displays, industrial terminals, embedded devices |
| CT-6000 Series | 60W | IEEE 802.3bt Type 3 | 12V / 24V / 48V | Industrial IoT, edge devices, control systems |
| CT-7500 Series | 75W | IEEE 802.3bt Type 4 | 12V / 24V / 48V | High-power network devices, automation equipment |
| CT-9000 Series | 90W | IEEE 802.3bt Type 4 | 12V / 24V / 48V | Network docks, high-power PoE devices, industrial equipment |
Ready to integrate PoE power?
Consult with our engineering team to select the exact module series for your device's power profile and thermal constraints.
Send Your Project RequirementChoose by Output Voltage
Corecon PoE modules support common embedded DC rails across different power series.
3.3V PoE Module
Available in CT-1300 Series for low-power embedded electronics and sensor applications.
5V PoE Module
Available in CT-1300, CT-3000, and CT-4500 Series for low-voltage embedded devices.
12V PoE Module
Available across CT-1300 to CT-9000 Series, depending on power requirement.
24V PoE Module
Available in CT-3000 to CT-9000 Series for industrial and commercial devices.
48V PoE Module
Available in CT-6000, CT-7500, and CT-9000 Series for higher-power applications.
PoE Module Applications
Corecon PoE PD modules are designed for OEM devices that need power and data through a single Ethernet cable.
IP Cameras & Security
Compact PoE modules for IP cameras, PTZ cameras, surveillance devices, and security equipment. We provide the ideal PoE power supply module for camera integration.
Wireless Access Points
PoE PD modules for wireless access points and connected network devices requiring reliable Ethernet power input.
POS Systems & Terminals
PoE power modules for POS terminals, smart displays, payment terminals, and embedded commercial devices.
Industrial IoT Devices
PoE modules for industrial controllers, sensors, gateways, edge devices, and IoT equipment.
PoE Lighting
PoE power modules for LED lighting systems and low-voltage network-powered lighting applications.
IP Communication
PoE modules for VoIP phones, intercom systems, access control terminals, and IP communication equipment.
Engineering Support for PoE Integration
Selecting a PoE PD module is not only about wattage. Output voltage, PD classification, load profile, isolation requirement, cable length, thermal margin, EMI, and mechanical integration all affect final device reliability. Corecon helps OEM teams review these details before production.
Share Your Device Requirement
Provide basic specs like voltage, power, and application space.
Select Standard PoE Module Series
We recommend the best fit from our CT-1300 to CT-9000 lines.
Test with Evaluation Board
Validate input, output, and load behavior on your lab bench.
Review Electrical and Thermal Performance
Ensure the module meets your system's reliability margins.
Customize if Required
Adjust pinouts, connectors, or voltages for unique form factors.
Move to Production Supply
Scale up with consistent quality and flexible OEM delivery.
Tested for Practical PoE Power Conditions
PoE-powered devices may face changing cable length, load profile, operating temperature, and installation environment. Corecon supports practical validation before production.
* Example internal test condition for reference. Final performance depends on module series, output voltage, load profile, and system design.
Request Test DataRequest a PoE Evaluation Board
Validate PoE input, DC output, load behavior, output ripple, and thermal performance before committing to production. Corecon evaluation boards help your engineering team test the module in a real application environment.
- RJ45 PoE input
- DC output terminal
- Load test interface
- Output ripple test point
- Suitable for CT-1300 to CT-9000 Series evaluation
- Engineering support available
Frequently Asked Questions
Common technical questions regarding Corecon PoE PD module integration.
What is a PoE PD module?
What PoE standards does Corecon support?
What power ranges are available?
What output voltages are available?
Can Corecon customize the PoE module?
What information should I provide for module selection?
Need a PoE Module for Your OEM Device?
Send your output voltage, power level, application, and mechanical requirement. Corecon engineers will help you select a standard PoE module or review a custom solution.
Our technical team reviews every inquiry to ensure optimal power integration for your specific device footprint.
